DESIGN Specifications
EXTERIOR SPECIFICATIONS:
Foundation:
- Full basement with minimum 7’-6″ poured 8″ concrete walls on footings
- Minimum 3,000 psi concrete, steel rebar as required
- Exterior bulkhead, interior door inside basement
- Pressure treated sills / Damp-proof below grade
- Crushed stone under concrete floor when conditions necessitate
Framing:
- 2”x 6” wood stud exterior walls, 16” on center
- Full 8’ ceiling height with 2”x 4” wood stud framing 16” on center for all interior walls
- 7/16” sheathing
- 3/4” tongue and groove engineered subfloors
Siding:
- “Certainteed” wood grain vinyl siding
- Soffits and rake trim aluminum wrapped
- House fully wrapped with a vapor barrier
Roofing:
- 5/8” sheathing
- Architectural asphalt self-sealing shingles with 30-year warranty
- Ice & water barrier installed on first 3’ of roof, felt paper on the balance
- 7/12” roof pitch with ridge vent & vented soffit
Windows:
- Double hung windows with extended windowsills & screens
- Shutters on all front windows
Gutters & Stairs:
- Aluminum gutters and downspouts on front and rear
- PVC stairs at entrances
Exterior Doors:
- Insulated fiberglass, six panel doors
- Vinyl clad exterior slide
Insulation:
- R-38 fiberglass insulation in ceilings
- Insulation in all walls per code
- All electrical outlets on exterior walls are insulated against air infiltration
